Trough bridge (sprayed)
The Trough Bridge (Sprayed) is a bridge structure that has undergone special spraying treatment. It is primarily used to span rivers, ravines, or other obstacles, providing convenient passage for vehicles, pedestrians, or pipelines. Its unique trough-shaped design makes the bridge structure more stable and enhances its load-bearing capacity. Meanwhile, the spraying treatment enhances the bridge's corrosion resistance, waterproofing, and durability.-
- Strong Stability: The trough-shaped design makes the bridge structure more stable, able to resist strong winds and water flow impacts.
- High Load-bearing Capacity: Through optimized design, the Trough Bridge (Sprayed) can bear significant vehicular and pedestrian loads, ensuring safe passage.
- Corrosion and Water Resistance: The spraying treatment provides excellent corrosion and waterproofing properties to the bridge surface, ensuring long-lasting usage even in harsh environmental conditions.
- Easy Construction: The modular design allows for quick assembly and disassembly, significantly reducing construction time.
- Environmental Friendliness and Energy Efficiency: The spraying material uses environmentally friendly coatings, free of pollution and toxicity, meeting the requirements of green buildings.
- Simple Maintenance: The bridge's simple structure leads to low maintenance costs and convenient daily maintenance.
-
Tile Parameter
Unit
Value
Pixel Pitch
mm/inch
16 / 0.63"
Pixel density
dots/sqm
3,906
Tile Pixels
Dots
16x16
Tile Size
mm/inch
256×256 / 10.1"×10.1"
Pixel type and configuration
Oval lamp 1R1G1B
Brightness
nits(cd/sq.m)
up to 8,500
Drive type
Static
Viewing angle-Horizontal
deg.
120(-60 ~ +60)
Viewing angle-Vertical
deg.
60(-30 ~ +30)
Red wavelength(domi.)
nm
620-625
Green wavelength(domi.)
nm
520-525
Blue wavelength(domi.)
nm
470-475
Lifetime(50% brightness)
Hours
100,000
Tile weight
g
980
-
